ABI-EL4008SPE Ethernet Switch


Artikelnummer: ABI-EL4008SPE Categorieën: , Tags: , ,

This highly specified IoT  “Internet of Things” 8 port PoE+  Fast Ethernet switch with 2 Gigabit Ethernet uplinks filters and forwards packets at full wire-speed for top performance. The ports automatically recognise all attached network equipment and choose the highest possible bit rate (10 or 100 Mbps) and transmission mode for each equipment. Standards-based flow control takes care of flawless Full Duplex and Half Duplex transmission modes.  The auto MDI/MDIX function eliminates the need (and risk of errors) for crossover patch cords.



8 Power Source Equipment Fast Ethernet ports provide 48V power to attached Powered Devices (max. 30W/port, max. 120W total)
2 Gigabit Ethernet uplinks are provided to attach the switch to a rapid backbone.
The switch can be set to automatic VLAN-mode by toggling a rear-panel switch. In this mode each of the 8 PoE+ ports only communicates with the uplinks, but the PoE ports do not communicate between each other.  This is an easy feature to ensure confidentiality between attached devices.
This “Internet of Things”  switch is eminently suited to power standard-compliant cameras, WiFi access points, card readers, access control & doorlock systems, sensor acquisition modules,  etc.
The switch comes in a new flatpack Aluminium housing which provides eminent cooling and ESD protection.
The switch is designed to our VertiGo principle: it can be mounted horizontal (shelf), vertical (wall, DIN rail) or at a 45° angle (Din rail) by means of the ingenious D-clip.

The PoE 120W power supply ABI-PS4053S25 is included in the package.

– 8 ports 10/100 Mbps with PoE+ PSE output
– 2 ports 10/100/1000Mbps
– Auto sense/auto negociate
– 53V power supply (ABI-PS4053S25)  included
– DIN-rail mount – 12 std positions wide
– Power drain max: 120W
Standards compliance:
IEEE 802.3i/u/ab
IEEE 802.3 az ; 802.3 az az Energy Efficient Ethernet
ESD IEC61000-4-2: 1a touch discharge level3, 1a air discharge level3
Net weight (kg/unit) :    0,675kg
Gross weight (kg/unit):  1,325kg

Extra informatie

Extra informatie

Gewicht 675 g
